Four Lane Log Saw

Features

  • High Cutting Capacity
  • Cutting bathroom rolls in 1-4 channels.
  • Cutting Jumbo rolls in single channel.
  • Trim removal prior to logs entering the accumulator or log saw.

Fully computerized controlling the following

  • Product and trim lengths
  • Cutting speed
  • Sharpening and auto dia. compensation system
  • Blade lubricantion spraying

Specifications



Cutting bathroom rolls in 1÷4 channels max. dia.  135 mm ( 5½” )
Jumbo roll in single channel  max. dia  230 mm ( 9” )
Cutting Speed 80 160 x 4 cuts / min
Blade diameter   600 - 800 mm
Power   15 kw
Measurements   7 x 2.5 x 2.5 m
